N900 Vortex

The 台制戰彈 is a double-sided mod made by TWPS spinner Joey. The name can be roughly translated as "Taiwan-made Warheads".

Construction

Parts needed

List from Joey's post in the TWPS penmodding group on Facebook:

• x2 雄獅 NO.900水性美工筆 (body)
• x2 700N (caps)
• x2 Pilot Opt Shaker (tip)
• x2 SKB G-2506 (grip)
• x1 Sander B-1700 (barrel)
• x2 Pilot G2 (grip)
• x1 Signo DX (grip)

=Additional items

• Tape

Text tutorial

Preparation

1. Cut both stripe section of the G2 grip from it's flat section.
2. Cut the front of both N900 body.
3. Cut 2x 2 mm and 1x 1.4 cm of Signo DX grip.
4. Cut both G-2506 grip to 2x 2 mm and 2x 4 cm.
5. Cut 2 2.5 mm ring off N900 cap.
6. Cut the Sander barrel to 3.5 cm

Assembly

1. Place the Opt tip inside the 700N cap.
2. Place the G2 stripe section over the 700N cap basis and Opt tip.
3. Place the 700N cap in the N900 barrel.
4. Add in this order: 2 mm of Signo DX grip, 2.5 mm of N900 cap and 4 cm of G-2506 grip on the N900 body (it should cover the tip structure).
5. Repeat on the other side.
6. Place the Signo DX and G-2506 grip on the Sander body and connect.
